PTFE Teflon Heat Shrink Tubing 4:1

PTFE Teflon Heat Shrink Tubing 4:1

SKU HS4-PTFE-012-4-CL

Login To View Discounted Pricing

$18.64 - $54.60
$18.64
$18.64 - $54.60
$18.64
Request a quote

Want to Sell Our Products. Click Here

  • Sold as 4’ Feet Stick
  • Exceptional resistance to corrosion: shields against harsh acids, alkalis, chemicals, and oils
  • High dielectric strength: provides excellent electrical insulation
  • Operating temperature range: -65°C to +200°C
  • Transparent (clear) color
  • Shrink Temperature: >350°C

Kable Kontrol® PTFE Heat Shrinkable Tubing delivers advanced protection and electrical insulation in the harshest industrial environments. Made from high-purity Teflon™ PTFE, this tubing excels in resisting corrosive substances and withstanding high voltages. Its wide temperature tolerance and chemical resilience make it a reliable choice for high-performance applications in aerospace, automotive, chemical processing, mechanical systems, transformers, and communication infrastructure. Designed for durability and efficiency, it offers long-term performance where other materials fail.

UL Listed, File E536025
RoHS Compliant

Property Test Method Standard
Tensile Strength(MPa) ASTM D2671 19
Elongation(%) ASTM D2671 200
Cold impact (-65°C) ASTMD 2671     Method C No cracking
Flammablity ASTM D2671 VW-1
Dieletric strength(kV/mm) VDE 0303 Part2 26
Volume resistivity(Ω.cm) VDE 0303 Part2 1.0X1014



Inside Diameter As Supplied (mm) Recovered (mm)
Inner Diameter Inner Diameter Wall Thickness
3mm (1/8”) 3.0＋0.8/-0.3 ≤0.75 0.30±0.05
4.5mm (3/16”) 4.5＋0.8/-0.3 ≤1.12 0.30±0.05
6mm (1/4”) 6.0＋0.8/-0.3 ≤1.50 0.30±0.05
9.5mm (3/8”) 9.5＋0.8/-0.3 ≤2.40 0.30±0.05
